SR-28

OEM Infrared or Radio Frequency Remote Control

Model: SR-28 — 28-button OEM remote control enclosure

Power: Operates on one (1) CR2025 lithium coin-style battery

Key Features:

  • 28-button rubber keypad in a compact form factor
  • Dual navigation key areas with multiple rocker keys
  • Supports infrared (IR) and radio frequency (RF) transmission
  • Designed for versatile OEM applications

Customization Options:

  • Key and case color variations
  • Optional backlighting

Availability: Offered in low to medium volumes with URC infrared database compatibility

General Specifications

Max Keys:

28

Dimensions:

4 x 1.6 x 0.5in.
105 x 40 x 14mm

Keypad Type:

Silicone Rubber

Feedback LED Available:

Yes

Overlay Available:

Yes

Back Label Available:

Yes

Feedback LED:

Yes

IR Lens:

No

Batteries:

1 x CR2025 Lithium Coin

Technical Specifications

Power Consumption:

Approx. 50mA at IR transmit

Transmission Distance:

20-30ft (6-9m) Standard

IR Frequency Options:

36KHz-56KHz

RF Frequency Options:

27MHz-2.4GHz

Operating Temperature:

+5C to +40C

Storage Temperature:

-40C to +70C

Humidity Range:

10% to 90% non-condensing

Compliance:

RoHS, REACH

Available Options

Custom Codes:

Yes

Button Colors:

Yes

Button Printing:

Yes

Case Color:

Yes

Custom Overlay /

Membrane Keypad:

Yes

RF Option:

Yes
