Low-volume Programmable Infrared Remote Control

The HRC-540A is a low-volume 54 button infrared remote control. It uses the NEC IR protocol as the default code format. Custom firmware can be created by mapping infrared codes from a single or multiple original remote controls. A recessed button area allows for custom overlays to be used to mask of any unused buttons and create a custom key layout. Customized printing on the overlay can be used to label button names as well as add branding, icons or other graphics.

The HRC-540A can be used for prototyping, remote consolidation and remote simplification projects. It is ideal for hospitality applications, where replacing the original remote control with a simple remote that is branded for a specific property is preferred. The HRC-540A can also be used to consolidate the primary functions from a TV, Set Top Box and other devices into a more intuitive and easy to use guest remote.

General Specifications

Max Keys:

54

Dimensions:

7.4 x 1.8 x 0.6in.
193 x 48 x 19mm

Keypad Type:

Silicone Rubber

Feedback LED Available:

Yes

Overlay Available:

Yes

Back Label Available:

Yes

Feedback LED:

Yes

IR Lens:

Yes

Batteries:

2 x AAA

Technical Specifications

Power Consumption:

~50mA @ Transmit

Transmission Distance:

~6-9m

IR Frequency Options:

38KHz

RF Frequency Options:

n/a

Operating Temperature:

+5C to +40C

Storage Temperature:

-40C to 70C

Humidity Range:

10% - 90% Non-Condensing

Compliance:

RoHS, REACH

Available Options

Custom Codes:

Yes

Button Colors:

No

Button Printing:

No

Case Color:

No

Custom Overlay /
Membrane Keypad:

Yes

RF Option:

No
