SC-14

OEM Infrared or Radio Frequency Remote Control

Model: SC-14 — 14-button OEM remote control

Power: Operates on two (2) AAA batteries

Key Features:

  • 14-button rubber keypad
  • Slim, two-column key layout
  • Supports infrared (IR) and radio frequency (RF) transmission

Applications: AV systems, education, polling, lighting, and security

Availability: Offered in low to medium volumes

Black remote control with white and orange buttons.

General Specifications

Max Keys:

14

Dimensions:

5.6 x 1.5 x 0.7in.

142 x 38 x 17mm

Keypad Type:

Silicone Ruber

Feedback LED Available:

Yes

Overlay Available:

Yes

Back Label Available:

Yes

Feedback LED:

Yes

IR Lens:

Yes

Batteries:

2 x AAA

Technical Specifications

Power Consumption:

Approx. 50mA at IR transmit

Transmission Distance:

20-30ft (6-9m) Standard

IR Frequency Options:

36KHz-56KHz

RF Frequency Options:

27MHz-2.4GHz

Operating Temperature:

+5C to +40C

Storage Temperature:

-40C to +70C

Humidity Range:

10% to 90% non-condensing

Compliance:

RoHS, REACH

Available Options

Custom Codes:

Yes

Button Colors:

Yes

Button Printing:

Yes

Case Color:

Yes

Custom Overlay /

Membrane Keypad:

Yes

RF Option:

Yes
