OEM Infrared or Radio Frequency Remote Control

Model: SR-11A — 11-key OEM remote control with navigation layout

Power: Operates on two (2) AAA batteries

Key Features:

  • 11-key rubber keypad design
  • Includes up, down, left, right, and enter navigation keys
  • Durable and ergonomic construction for reliable operation
  • Suitable for various OEM applications requiring directional control

Customization Options:

  • Key and case color variations
  • Optional backlighting
  • Custom infrared (IR) and radio frequency (RF) transmission options

Integration: Compatible with Universal Remote Control (URC) infrared device databases

Availability: Offered in low to medium volumes with infrared (IR) or radio frequency (RF) transmission options

General Specifications

Max Keys:

11

Dimensions:

4.5 x 1.4 x 0.9in.
115 x 35 x 22mm

Keypad Type:

Silicone Rubber

Feedback LED Available:

Yes

Overlay Available:

No

Back Label Available:

Yes

Feedback LED:

Yes

IR Lens:

No

Batteries:

2 x AAA

Technical Specifications

Power Consumption:

Approx. 50mA at IR transmit

Transmission Distance:

20-30ft (6-9m) Standard

IR Frequency Options:

36KHz-56KHz

RF Frequency Options:

27MHz-2.4GHz

Operating Temperature:

+5C to +40C

Storage Temperature:

-40C to +70C

Humidity Range:

10% to 90% non-condensing

Compliance:

RoHS, REACH

Available Options

Custom Codes:

Yes

Button Colors:

Yes

Button Printing:

Yes

Case Color:

Yes

Custom Overlay /

Membrane Keypad:

No

RF Option:

Yes
